Stratasys Objet1000 Plus - Operating and Maintaining the Objet1000 Plus 3 D Printer

DOC-06810 Rev.B 6-1
6
Operating and Maintaining the
Objet1000 Plus 3D Printer
StartingthePrinter 6-2
LoadingModelandSupportContainers 6-4
ProducingModels 6-6
PreparingthePrinter 6-6
StartingPrinting 6-7
PrinterInterfaceColorKey 6-8
PrintingIndicators 6-9
ResumingProductionAfterPrintinghasStopped 6-10
ChangingthePrintingMaterial 6-13
AdvancedSettings 6-17
KeepingthePrinterinIdleMode 6-18
ShuttingDownthePrinter 6-19
MaintainingthePrinter 6-22
RoutineMaintenanceSchedule 6-22
UVLampCheck 6-24
PatternTest 6-24
ImprovingPrintQuality 6-26
CleaningthePrintHeads,RollerandWiper 6-27
CleaningtheRollerWasteCollectorandInspectingtheRoller
Scraper 6-30
ReplacingtheRollerScraper 6-34
AligningthePrintHeads 6-36
Optimizing(Calibrating)PrintHeads 6-40
ReplacingPrintHeads 6-48
TestingandCalibratingtheUVLamps 6-58
ReplacingtheRollerWasteTube 6-61
CalibratingtheLoadCells 6-64
ReplacingtheUVLamps 6-66
Built-inTests 6-72
ReplacingWasteContainers 6-77
CleaningtheExteriorPanels 6-77
