2. Loosenthescrewssecuringthesuctiontube.
Figure6-37Suctiontubecorrectlypositioned
3. Lowerthesuctiontubesothattheholeinthepanelbehindthetubeis
visible,andtightenthescrewstosecurethetube.
4. Attachtheright-UV-lampassemblytotheprintblockandreconnectthe
UVpowerandfancables.
Replacing the
Roller Scraper
Youshouldreplacetherollerscraperblade—
•after1,000hoursofprinting.
•ifitdoesnoteffectivelykeeptherollerclean.
Youshouldperiodicallytesttheeffectivenessoftherollerscraperwhenyou
cleantherollerwastecollector.See"CleaningtheRollerWasteCollectorand
InspectingtheRollerScraper"onpage6-30.
Toreplacetherollerscraper:
1. Prepare—
❒ anewrollerscraperblade
❒ aPhillips1x75mmscrewdriver
❒ a2.5-mmanda2-mmhex(Allen)key
2. RemovetherightUVlampandtherollerwastecollectorcovering(see
steps3to7onpage6-31).
3. Loosenthetwoscrewssecuringtherollerwastecollectorandpullitout.
Figure6-38Removingtherollerwastecollector
