Stratasys Objet1000 Plus - Monitoring and Managing Print Jobs

Objet1000 Plus User Guide 5 Using Objet Studio
DOC-06810 Rev.B 5-75
Monitoring and Managing Print Jobs
IntheJob ManagerscreenofObjetStudio,youmonitorandmanagejobs
senttotheprinter.ThereareafewdifferencesbetweenObjetStudioonclient
workstationsandonthecomputerconnecteddirectlytothe3Dprinter—the
serverworkstation.
•ObjetStudioinstalledonaclientcomputeronlydisplaysthequeueand
statusforjobssenttothe3Dprinterserverfromthatcomputer,andit
allowstheusertoeditonlythesejobs.
Note: IfthereareseveralPolyJetprintersonthelocalnetwork,client
computerscanconnecttoanyofthem,butonlyoneatatime.
•ObjetStudioinstalledonthecomputerdirectlyconnectedtoaspecific3D
printer(server),displaysthequeueandstatusforalljobssenttothat3D
printerbytheserverandbyallclientcomputersonthenetwork.Italso
allowseditingandmanipulationofalljobs,andenablesre-sending
previously-printedjobstotheprinter.
IfObjetStudioisnotconnectedtoaprinter(orprinterserver),youcan
preparetrayfilesforanyPolyJetprinter.Later,thesefilescanbeusedby
ObjetStudioontheappropriateprinterserver.
Job Manager
Screen
TheJob Managerscreenontheclientandserverworkstationslooks
identical.Theonlydifferenceisthatoptionsonlyrelevanttotheserver
workstationaredisabledforclientinstallations.
Figure5-101Job Managerscreen
TheJob Managerscreenisdividedintopanels:
•JobsQueue
•PrintingProgress
•History
•AvailableResources
•MaterialConsumption
•TrayPreview
•Waste
