Stratasys Objet1000 Plus - Objet Studio Software

Objet1000 Plus User Guide 3 Introducing the Objet1000 Plus 3D Printing System
DOC-06810 Rev.B 3-8
Objet Studio Software
TheObjetStudioprogramfortheObjet1000Plus3Dprintingsystemconsists
oftwomainscreens:
•TraySettings/ModelSettings
•JobManager
TraySettings/ModelSettings
IntheTray SettingsandModel Settingsscreens,youpreparesourcefilesfor
productioninObjet1000Plus3Dprinters.ObjetStudiooffersyouawide
varietyoffile-preparationoptions,butalwaysconsistsofthefollowingbasic
procedure:
1. Placingoneormoreobjectsonthebuild tray
2. Positioningtheobject(s)onthetray
3. Configuringobjectandtrayparameters
4. Savingthetrayconfigurationasanobjtf(trayformat)file
5. SendingtheobjtffiletotheObjet1000Plus3Dprinterforproduction
UsingObjetStudiotoperformthesetasksisdescribedindetailinChapter5,
"UsingObjetStudio".
JobManager
TheJob Managerscreenisdifferentforclientworkstationsandforthe
computerconnecteddirectlytotheObjet1000Plus3Dprinter.
•InObjetStudioinstalledonthedirectly-connectedcomputer(server),the
Job Managerscreendisplaysthequeueandstatusforalljobssenttothe
3Dprinterbytheserveritselfandbyallclientcomputersonthenetwork.
Alljobsdisplayedcanbeeditedandmanipulated.
•InObjetStudioinstalledonclientcomputers,theJobManagerscreen
displaysthequeueandstatusonlyforjobssenttoa3Dprinterserverfrom
thatcomputer.Onlythesejobscanbeeditedandmanipulatedfromthe
clientcomputer.
Clientcomputerscanbeconnected,viathelocalnetwork,toPolyJet3D
printers,butonlytooneatatime.TheJob Managerscreendisplaysthestatus
ofthe3Dprintertowhichtheclientiscurrentlyconnected.
