Stratasys Objet1000 Plus - Screen Layout

Objet1000 Plus User Guide 5 Using Objet Studio
DOC-06810 Rev.B 5-44
Screen Layout
ObjetStudioautomaticallyadjuststhedefaultscreenlayouttodisplaythe
optimumviewsofthebuildtrayandthemodeltree.Youcanviewmodels
fromdifferentperspectivesbychangingthescreenlayout.
Tochangethescreenlayout:
➢ OntheViewflyouttoolbar,selectSingleView,or4Views.
Figure5-54Screenlayouticons
❒ SingleView isthedefaultscreenlayout.
❒ 4Views displaysperspective,top,frontandrightviews.
Figure5-55Single-viewscreenlayout
Figure5-564-viewscreenlayout
