Workflows
WithObjet1000Plusprintingsystems,youhavegreatflexibilityinpreparing
modelfilesandprintingthem.Belowarethemajorworkflowsavailable.
Stage Workflow A Workflow B Workflow C
CAD program*
• Designa3Dobject.
• Saveitasasinglestl
file.
• Designa3Dobject.
• Saveitasan
assemblyofstlfiles.
• Designa3Dobject.
• Applycolorstoparts.
Objet Studio /
GrabCAD Print*
• Open(Insert)thestl
file.
• Separatetheobject
intoitscomponents
(“shells”).
• Assignmaterialsto
thecomponents.
• Open(Insert)thestl
filesasanassembly.
• Assignmaterialsto
theassembly’s
components.
• Open(Insert)anobjdf
file(ObjetStudio).
(objdf filescontain
model-material
information.)
lSavetheobjectasanobjdffile(ObjetStudio,
optional).

lSavethebuildtray./Sendthebuildtotheprinter.
Objet1000 Plus Printer
Models are produced in the printer.

lRemovetheSupportmaterialfromthemodels
Finished model
Finished model.
3Dprintingworkflows,fromdesigntofinishedmodels
*Inadditiontotheoptionsshown,GrabCADPrintsupportsmostnativeCADfileformats.
