5. Loosenthetwoscrewssecuringthesuctiontubeontheprintblock.
Figure6-33Liftingthesuctiontube
6. Liftthesuctiontubetosecureitinaraisedposition.
7. Removethetwoscrewssecuringthecoveringoftherollerwastecollector
andremoveit.
Beverycarefultosavethecoveringscrews.Thesearespecialscrews;ifthey
arelost,youneedtoorderreplacements.
Figure6-34Removingtherollerwastecollectorcovering
8. Removethecoveringbypullingitout,andthenlowerit.
