Wire Routing: 4A-5
1
2
3
5
6
44
I9J011410004-02
1. Battery charge coil 3. Cylinder temp. sensor lead wire 5. MAP sensor
2. Battery charge coil lead wire 4. Clamp 6. IAC valve
