VAP416 Installation & Operation Manual
TD-1/07-004
Armed zones (Zones and related partitions in partition LEDs)
Last alarm zone (Zones and related partitions in partition LEDs)
Bypassed zones (Zones and related partitions in partition LEDs)
Troubles (look at trouble codes table)
4.2.8 Trouble Codes
If 16. LED is lightning with "Trouble" Led together (All LEDs in VPC108 keypad), this
means there is no communication between keypad and panel. If any trouble occurs,
"Trouble" LED becomes ON. Trouble report can be seen as follows;
Date and/or time is not set
4.2.9 Error Codes
If there is a long "beep" sound, it means there is an error in the operation. Under this
condition, some zone leds which shows error type are lightning with "trouble" LED.
Invalid address has been entered
Your permissions are limited
The partitions you try to arm are
already armed
Invalid code has been entered
Entered value is out of limit. For
example; if you enter a value over
than 23 for the time
Length of data that you have
entered is wrong. For example; if
you enter 2 digits instead of 4
digits
Feature you have tried to use is
closed
The function you are trying to use
is invalid
The parameter you are trying to
use is invalid. Example: If you try
to test 3.Central Station, keypad
displays this trouble
