Electrical & Mechanical Features
230V AC Voltage
Fuse AC Voltage(200 mA)
Power supply for external units with electronic fuses
Fused and short-circuit protected 12V power outputs (12V 1A siren output, 1A
AUX and keypad output).
Current limited battery charge circuit
2 x 12V 7Ah batteries can be connected
PGM1,2,3 output current: 300mA max. Total current output of PGM1,2,3: 500mA
max.
SRN output current: 500mA max
Metal box dimensions: 310mm(width) x 302mm (Length) x 83mm (Height)
Weight( ± 2 gram) : 2780 gram / 3100 gram ( Packaged)
Optional Modules
Voice recording module,
Voice message module (includes 8
messages),
Remote Control module,
4-Zone expansion module,
Relay module,
USB PC link module,
RS232 PC link module,
X10 module,
Network module,
3. MOUNTING
!!! WARNING !!!: Don’t connect power to panel without finishing wiring.
3.1. GENERAL
Drill necessary holes on the wall and then mount panel case to wall by using proper
holes. Metal cover of panel constitute of body and cover. Cover is opened by
removing two screws. Detectors, siren, and telephone line are connected to Panel by
using proper cables. (It is recommended to you use wire screened cable or silver
foiled LIYCY cable and ground the mains voltage) Before connecting supply voltage,
make sure that all connections are made correctly. Also it is recommended to
connect keypad cable foil to panel GND and keypad GND. For the mains voltage
connection, 3x0.75 mm² standard cable may be used. Descriptions of panel terminals
are in the following picture.
