8.3 ZONE SETTINGS
8.3.1. Zone Wiring
The zone must be set according to the type and connection type of detector. The
setting can be done form the detector connections. The type of contact can be
selected as NC or NO. The connection type can be selected without resistor, single
end of line resistor or double end of line resistor. The zones which are not available
can be closed. If Z1...Z16 are doubled the doubled zones are doubled. That is if Z1 is
active also Z17 is active. The settings are below;
Zone Wiring Type
1.option=NC=on, NO=off
4.option=Zone enable/disable
(*) Zone expansion module and zone doubling can not be used together.
Address 20 01. < IP >
Display for settings:
LED 20 01 (wait)
LCD ZONE SETTINGS→CONNECTION TYPE→CONNECT TYPE (wait)
Change for settings:
LED 20 01 <Value> "√"
LCD ZONE SETTINGS→CONNECTION TYPE→CONNECT TYPE
<Value>
Shown/Entered value: <Value>, 1,2,3,4 multi selection from the table.
Factory default: 1,4 selected
Example: To set Zone 1 to NO contact do
20 01 1 (turn off) √
Zone Wiring from 2 to 16
Addresses 20 02 ... 20 16. < IP >
Factory default: 1,4 selected
Zone Wiring from 17 to 32
Addresses 20 17 ... 20 32. < IP > (If zone doubling enabled)
Factory default: 1,4 selected
8.3.2. Assign A Zone To A Partitions
Each zone can be assigned to A,B,C,D. A zone can be assigned to only one
partition. There can be a couple of zones of a partition. For the factory setting SPT is
closed and zones are related to a partition. The meaning o these selections in these
addresses are below;
Zone 1 Partition
ABCD: 1.option=A, 2.option=B, 3.option=C, 4. option=D
SPT: 1.option=Interior, 2.option=Window, 3.option=Door, 4.option=Exterior
If it is used with SPT, only 1=Interior is recommended setting. Page 30 for
the details.
Address 21 01. < IP >
To Next Page
