VAP416 Installation & Operation Manual
TD-1/07-004
56 / 81
Display for settings:
LED 21 01 (wait)
LCD ZONE SETTINGS→PARTITION→ZONE (wait)
PARTITION:
Change for settings:
LED 21 01 <Value> "√"
LCD ZONE SETTINGS→PARTITION→ZONE
PARTITION: <Ayar>
Shown/Entered value: <Value>, 1,2,3,4 single selection from the list
Factory default: 1 selected
Example: To assign Zone 1 to C partition
21 01 3 √
Zone Partition from 2 to 16
Addresses 21 02 ... 21 16. < IP >
Factory default: 1 selected
Zone Partition from 17 to 32
Addresses 21 17 ... 21 32. < IP > (If zone doubling enabled)
Factory default: 1 selected
8.3.3. Zone Type
The zone type can be selected according to place and device type the code which
will send to CMS is defined by panel for a zone only one type can be selected. The
selections of Entry/Exit and Follower can be done by using zone adjustment.
Zon Type
Code
Description
Free Zone
0
This zone has no effect on alarm events. It can be
used to activate PGM(s)
Door
1
Used with magnetic contacts that is connected doors. If
Panel is configured as Smart Partition, Panel
automatically assigns that zone to Door Partition.
Window
2
Used with magnetic contacts that is connected
windows. If Panel is configured as Smart Partition,
Panel automatically assigns that zone to Window
Partition.
Interior
3
Used with interior areas. If this zone is used as follower
zone, you should select follower zone option in
address of 23 0X (X= zone number).
Exterior
4
Used with detectors that is connected out of home.
24 Hour
5
This zone alarms if panel armed or disarmed when
zone is active.
Fire
6
This zone alarms if panel armed or disarmed when
zone is active. To silent alarm from this zone enter
user code or press 0 (long).
Panic
7
This zone alarms if panel armed or disarmed when
zone is active and communicator sends Panic alarm
code to Central monitor station.
Duress
8
This zone alarms if panel armed or disarmed when
zone is active and communicator sends Duress alarm
code to Central monitor station.
