Teknim VAP416 - Zone Trigger Delay

VAP416 Installation & Operation Manual
TD-1/07-004
58 / 81
Meaning
Option
On
Off
End door
1
Yes
No
Follower*
2
Yes
No
Entry/Exit Zone*
3
Yes
No
Silent Zone
4
Yes
No
Manual Bypass
5
Can't bypass
Can bypass
Automatic Bypass
6
Can't bypass
Can bypass
Cross Zone**
7
Yes
Normal Zone
* A zone can not be done at the are time both of entry/exit and follower.
** Cross zone feature can be used to door, window, interior and exterior zones.
The features of cross zone is not recommended using for entry/exit and
follower.
Zone 1
Address 23 01. < IP >
Display for settings:
LED 23 01 (wait)
LCD ZONE SETTINGS→EXTRA SETTINGS→ZONE OPTIONS (wait)
Change for settings:
LED 23 01 < Ayar > "√"
LCD ZONE SETTINGS→EXTRA SETTINGS→ZONE OPTIONS
<Value>
Shown/Entered value: <Value>, 1...7 multi selection from the table.
Factory default: 3 selected (Entry/Exit Zone)
Example: To set zone 1 as silent zone do
23 01 4 (turn on) √
Zone 2
Address 23 02. < IP >
Factory default: 2 (Follower)
From 3 to 16
23 03 ... 23 16 adreslerindedirler. < IP >
Factory default: -
From 17 to 32
23 17 ... 23 32 adreslerindedirler. < IP > (If zone doubling enabled)
Factory default: -
8.3.5. Zone Trigger Delay
Panel does not detector running of contact short time. The factory setting is enough
for lots of applications. The readjusting is not reordered. Entered the is value x 30 (for
5 seconds, 5x30=150 msec)
Zone 1 Trigger Delay
Address 24 01. < IP >
Display for settings:
LED 24 01 (wait)
LCD ZONE SETTINGS→LOOP SETTINGS→ZONE DELAY (wait)
Change for settings:
LED 24 01 <Value> "√"
LCD ZONE SETTINGS→LOOP SETTINGS→ZONE DELAY
<Value>
Shown/Entered value: <Value>, Number
