Teknim VAP416 - PGM Settings

VAP416 Installation & Operation Manual
TD-1/07-004
50 / 81
Type
Description
Parameter
Def.
Value
2
PGM becomes active while
selected partitions are active
The table values of the selected partition(s) are
added to each other and entered.
Exp: For B and C partitions, 2+4=6 is entered
Part.
Value
A
1
B
2
C
4
D
8
15
3
PGM is activated when selected
partitions are armed
The table values of the selected partition(s) are
added to each other and entered.
Exp: For B partition, 2 is entered
Part.
Value
A
1
B
2
C
4
D
8
15
4
PGM is activated on fire.(Fire
siren can be connected)
Any value is not entered. When the fire alarm is detected, PGM
continuously activates.
-
5
Power of fire detector is
connected to PGM.
The resetting time of the detector between 1...255 as second.
10
6
PGM is connected to additional
siren that is related with
selected partitions
The table values of the selected partition(s) are
added to each other and entered.
Exp: For A and D partitions, 1+8=9 is entered
Part.
Value
A
1
B
2
C
4
D
8
15
7
PGM is activated while selected
troubles occur
The table values of the
selected troubles are
added to each other
and entered.
Exp: For Battery Low
and Zone Trouble,
2+16=18 is entered.
Trouble
Value
Trouble.
Value
AC Fail
1
Tel.Line
Fail
8
Battery
Low
2
Zone
Trouble
16
Time
Loss
4
Battery
Fail
32
63
8
PGM controls magnetic lock
connected to door
The keeping open time of the magnetic lock between 1...255 as
second.
5
9
PGM is activated/deactivated in
time specified in Timer1 or
Timer2 (*)
The working time between 0...255 as minute.
Note: If the number is 0, it works until closing by another source.
0
10
PGM random output ON/OFF
Param.
PGM ON Time
PGM OFF Time
0
1...255 second
1...255 second
1
1...255 minute
1...255 minute
2
1...63 second
1...255 second
3
1...63 minute
1...255 minute
0
11
PGM is activated on ARM
The working time between 0...255 as minute.
Note: If the number is 0, it works until closing by another source.
0
12
PGM is activated on DISARM
The working time between 0...255 as minute
Note: If the number is 0, it works until closing by another source.
0
13
PGM is activated on RC panic
button
The working time between 0...255 as minute.
Note: If the number is 0 and when the button is pushed the mode
changes.
0
14
PGM is activated on relevant
alarm occur
The table values of the
selected alarms are
added to each other
and entered.
Exp: For Intruder and Fire alarms 1+4=5 is entered.
Alarm
Value
Alarm
Value
Intruder
1
Duress
8
Panic
2
Tamper
16
Fire
4
Medical
32
63
8.2.4.1 PGM Settings
PGM1 Usage Type
Address 13 01. < IP >
Display for settings:
