Chapter 6: Sequence Graphing 161
Selecting Axes Combinations
Selecting Axes CombinationsSelecting Axes Combinations
Selecting Axes Combinations
Setting the Graph Format
Setting the Graph FormatSetting the Graph Format
Setting the Graph Format
To display the current graph format settings, press y.. Chapter 3 describes the
format settings in detail. The other graphing modes share these format settings. The
axes setting on the top line of the screen is available only in Seq mode.
Setting Axes Format
Setting Axes FormatSetting Axes Format
Setting Axes Format
For sequence graphing, you can select from five axes formats. The table below shows
the values that are plotted on the x-axis and y-axis for each axes setting.
Time Web uv vw uw
Type of sequence plot (axes)
RectGC Polar GC
Rectangular or polar output
CoordOn CoordOff
Cursor coordinate display on/off
GridOff GridOn
Grid display off or on
AxesOn AxesOff
Axes display on or off
LableOff LabelOn
Axes label display off or on
ExprOn ExprOff
Expression display on or off
Axes Setting x-axis y-axis
Time n u(n), v(n), w(n)
Web
u(n
N1), v(nN1), w(nN1)
u(n), v(n), w(n)
