SPECIFICATIONS AND GENERAL INFORMATION
4203781 First Edition 2-7
2
Steering
Cutting Units
Accessories and Miscellaneous
Repair Specifications
Gear Pump—Rear Cover-to-Pump Body Bolt Torque lb-ft (N·m) 20 (27)
Mow Solenoid Valve Torque
lb-ft (N·m) 24—26 (32.5—35.3)
Mow Solenoid Valve Nut Torque
lb-ft (N·m) 5—7 (6.8—9.5)
Blade Brake Relief Valve Torque
lb-ft (N·m) 33—37 (44.7—50.2)
Deck Valve System Relief Valve Torque
lb-ft (N·m) 24—26 (32.5—35.3)
Hydraulic Oil Tank Capacity
gal (L) 17 (64.3)
Front Lift Cylinder Rod Nut Torque
lb-ft (N·m) 50 (68)
Wing Lift Cylinder Rod Nut Torque
lb-ft (N·m) 95 (129)
Test and Adjustment Specifications
Steering System Leakage Test—Cylinder Leakage pt (L) Zero—Nominal Amount
Rear Axle Alignment Toe-In Measurement
in. (mm) 0.0625 (1.6)
Rear Axle Spindle Arm-to-Axle Stop Measurement
in. (mm) 0.030—0.060 (0.76—1.5)
Repair Specifications
Steering Wheel Nut lb-ft (N·m) 28—30 (38—41)
Steering Valve Rotor-to-Stator Clearance
in. (mm) 0.003 (0.08)
Steering Valve Metering Assembly Screw Torque
lb-in. (N·m) 11—13 (1.2—1.5)
Steering Valve Port Cover-to-Port Manifold Nut Torque
lb-ft (N·m) 18—22 (24—30)
Steering Cylinder Ball Joint-to- Steering Arm Torque
lb-ft (N·m) 40 (54)
Tie Rod Ball Joint-to-Steering Arm Torque
lb-ft (N·m) 30 (41)
Repair Specifications
Blade Retaining Screw lb-ft (N·m) 75 (100)
Adapter Screws
lb-ft (N·m) 35–40 (47–54)
OPS Mounting Hardware
Mounting Hardware Torque lb-ft (N·m) 135—165 (183—224)
Fuel Tank
Capacity gal (L) 20 (75.7)
Front Tires
Size 26 x 12.00-12
Type 6-Ply
Air Pressure
psi (bar) 16—20 (0.55—0.69)
Mounting Bolt Torque
lb-ft (N·m) 100—120 (135—162)
