Textron Jacobsen HR-5111 User Manual

2-8 4203781 First Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Rear Tires
Size 23 x 10.50-12
Type 4-Ply
Air Pressure
psi (bar) 8—10 (55—69)
Mounting Bolt Torque
lb-ft (N·m) 40—50 (54—68)
Mower Speed
Transport—2WD mph (km/h) 0—15 (0—24)
Transport—4WD
mph (km/h) 0—8.4 (0—13.5)
Mowing
mph (km/h) 0—7.5 (0—12)
Reverse
mph (km/h) 0—6 (0—9.7)
Brakes
Brake Pedal Free Travel in. (mm) 0.125 (3)
Park Brake Lever Force
lb (kg) 36—42 (16—19)
Brake Caliper Nut Torque
lb-ft (N·m) 37 (51)
Traction Pedal
Traction Pedal Mounting Bracket Nut Torque lb-ft (N·m) 25 (34)
Traction Pedal Ball Joint Nut Torque
lb-ft (N·m) 50 (68)
Engine
Manufacturer/Model Kubota
®
Tier 2/V2203-DI-B
Engine Type 4-stroke, diesel
Fuel Requirement No. 2-D diesel fuel (Cetane Rating-45)
Number of Cylinders/Configuration 4, in-line
Displacement
cu in. (cc) 131.1 (2148)
Bore x Stroke
in. (mm) 3.43 x 3.64 (87 x 92.4)
Power Output
hp (kW) 49 (36.5) @ 2500 rpm
Firing Order 1-3-4-2
Compression Ratio 19-1
Injection Timing (Before T.D.C.)
degrees 18°
Cooling System liquid cooled
Cooling System Capacity
qt (L) 8 (7.6)
Idle Speed 850-900 rpm
Maximum Speed (No Load) 3050 rpm
Oil Sump Capacity
qt (L) 10 (9.5)
Alternator 12 volt, 45 amp
Dry Weight
lb (kg) 397 (180)
