ACCESSORIES AND MISCELLANEOUS REPAIR
4203780 First Edition 9-15
9
Figure 9-20: Mini Seat Suspension
1 Push Nut (4) 6 Spring Hanger 11 Nut
2 Pivot Shaft (2) 7 Lock nut 12 Spring Kit
3Knob 8Spring (2) 13Screw
4 Flat Washer 9 Bearing (4)
5 Bumper (2) 10 Lock Washer
6
1
T
N
1
8
0
5
2
3
4
1
5
7
8
9
9
10
11
12
13
