ENGINE
4203780 First Edition 3-19
3
!
WARNING
Figure 3-34
23. Using an engine hoist, support the engine (43) and
remove the four engine mounting bolts (41) and flat
washers (42).
24. Check for any connected wires and components and
carefully remove the engine from the machine.
25. Place the engine on a suitable stand or workbench
that will support the full weight in a safe manner while
preventing damage to the engine.
Prevent personal injury. Use a properly rated
lifting device. Always be sure the load is
balanced before lifting.
45
TN1995
41
42
43
To Next Page
