2-4 4203781 First Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Component Location
See Figures 2-6 and 2-7.
!
CAUTION
Figure 2-6: Component Location—Right Side
Become familiar with operator controls, machine
components, and correct operating procedures
before beginning repair procedures.
1 Seat 6 Left Cutting Unit
2 Instrument Panel 7 Center Cutting Unit
3 Steering Wheel 8 Right Cutting Unit
4 Traction Pedal 9 Fuel Tank
5Brake Pedal 10Hood
TN2166
1
3
2
5
6
7
8
4
9
10
