ENGINE
4203781 First Edition 3-3
3
Component Location
Kubota V2203-M-E3B
See Figures 3-1 and 3-2.
Figure 3-1: Component Location—Right Side
1 Hydraulic Oil Cooler 6 Coolant Overflow Reservoir 11 Engine Coolant Temp Switch
2 Engine Oil Cooler 7 Hydraulic Oil Filter (2) 12 Fan Drive Belt
3 Radiator 8 Oil Pressure Sending Unit 13 Engine Temperature Sensor
4 Thermostat 9 Starter Motor 14 Fuel Pump
5 Air Cleaner Assembly 10 Alternator
1
8
6
12
9
5
3
4
7
14
TN2123
2
13
10
11
