CUTTING UNITS
4203781 First Edition 8-3
8
Component Location
See Figure 8-1.
Figure 8-1: Component Location
1 Swivel Caster Wheel Assembly (6) 6 Wing Lift Arm (2) 11 Anti-Scalp Wheel (4)
2 Deck Motor (7) 7 Outer Wing Caster Arm (2) 12 Front Deck Assembly
3 Right Wing Deck Assembly 8 Left Wing Deck Assembly 13 Front Caster Arm (2)
4 Front Deck Lift/Push Arms 9 Height-of-Cut Spacers 14 Anti-Scalp Wheel
5 Inner Wing Caster Arm (2) 10 Fixed Caster Wheel Assembly (2)
TN2096
2
4
11
14
13
10
9
7
6
8
12
3
5
1
