4-4 4203781 First Edition
ELECTRICAL
4
Specifications
Test and Adjustment Specifications
Specification
Resistance Across Solenoid Coil—Front Mow
Solenoid Coil at 68° F
ohms 7.1 ± 10%
Resistance Across Solenoid Coil—Right Mow
Solenoid Coil at 68° F
ohms 7.1 ± 10%
Resistance Across Solenoid Coil—
Left Mow Solenoid Coil at 68° F
ohms 7.1 ± 10%
Resistance Across Solenoid Coil—
4WD Solenoid Coil at 68° F
ohms 8.8 ± 10%
Resistance Across Solenoid Coil—
4WD Rev Solenoid Coil at 68° F
ohms 8.8 ± 10%
Fuel Level Sender Resistance Between Terminals at
Full Position
ohms 32 ± 10%
Fuel Level Sender Resistance Between Terminals at
Empty Position
ohms 256 ± 10%
Resistance Across Fuel Shutoff Pull-In Coil at 68° F
ohms 0.5 ± 10%
Resistance Across Fuel Shutoff Hold-In Coil at 68° F
ohms 15 ± 10%
Resistance Across Cruise Control Magnet at 68° F
ohms 4.2 ± 10%
Mow Solenoids Nut Torque
lb-ft (N·m) 5–7 (6.8–9.5)
4WD Solenoids Nut Torque
lb-ft (N·m) 4–5 (5.4–6.8)
