Traction Pump U-Joint
Removal and Installation
See Figure 5-43.
Figure 5-43
1. Park the mower safely. (See “Park Mower Safely” on
page 1-6.)
2. Remove the 4WD valve. (See “4WD Valve” on
page 5-52.)
NOTE
It may be necessary to rotate the flywheel to access all of
the pump drive flange screws.
