8-6 4203781 First Edition
CUTTING UNITS
8
Final Adjustments
1. Make a sample cut with front deck and wing decks. If
front deck is cutting at the same height as wing
decks, unit is ready.
2. If front deck is cutting lower, add 1/8 inch flat washer
to front caster height-of-cut spacer. Add 1/8 inch
shim to lift arm to maintain proper deck rake.
3. If front deck is cutting higher, you may have to loosen
the caster wheel arms and lower the deck to the next
position. Retighten caster arms, again removing
shims from lift arms to maintain proper deck rake.
4. Once the deck is cutting properly, an operator should
only have to move the 1/2 inch height-of-cut spacers
to change the height of cut, and the deck rake will
follow throughout the range.
