HYDROSTATIC POWER TRAIN
5
1. Park the mower safely. (See “Park Mower Safely” on
page 1-6.)
2. Remove seat and seat platform. (See “Seat and Seat
Platform” on page 9-10.)
3. Disassemble traction linkage as shown in
Figure 5-64 on page 5-68.
NOTES
When removing rod ends (25 and 30) from traction pump
adjusting rod (28), record the number of turns needed to
remove the rod ends to ensure correct assembly.
4. Place parts in assembly order on a clean work area
as they are removed.
Assembly Notes
• Assemble the traction linkage by reversing the order
of disassembly.
• Install rod ends (25 and 30) on traction pump
adjusting rod (28), using the same number of turns
as recorded during removal.
• Adjust traction linkage. (See “Traction Linkage
Adjustments” on page 5-29.)
