4-6 4203781 First Edition
ELECTRICAL
4
Motors and Generating Devices
Electric Motors (may also
include “AC” or “DC.”)
Stator
Alternator
Actuating Devices
Solenoid Valve PTO Clutch
Engine-Related Devices
Ignition Coil Spark Plug
Regulator Fuel Shutoff Solenoid
Lights
Single-Element Light Dual-Element Light
M
G
G
U
3
U
Pull-In Hold-In
