Textron Jacobsen SLF530 User Manual

5-18 673831-Rev A
HYDROSTATIC POWER TRAIN
5
Traction Circuit—Reverse 2WD/4WD
Schematic
See Figures 5-9 and 5-10.
Figure 5-9
1 Return oil from front reel valve 3 Drain oil from front reel motors 5 Charge pressure oil to 4WD valve (port B)
2 Return oil from lift valve (Port T) 4 Charge pressure oil to 4WD valve (Port A)
MAR0076
Right Front
Wheel Motor
Left Front
Wheel Motor
.39 ci .39 ci .39 ci
4060 psi
4060 psi
200 psi
2.14 ci
3000
RPM
A
B
Gear
Pump
0.651 ci
0.651 ci
Rear
Reel
Valve
A
B
P
G
T
SOL2
SOL1
Left Rear
Reel Motor
Right Rear
Reel Motor
10
Micron
25 psi
Crack
Bypass
Charge
Filter
Oil
Cooler
100
Mesh
Screen
507 PSI
CHG
DR
PB1
PB2
Brake
Valve
1
2
4
5
3
1X2
1X2
RL
LR
13 ci
13 ci
Suction Oil Operating Pressure Oil Charge Pressure Oil Drain or Return Oil
