Textron Jacobsen SLF530 User Manual

6-14 673831-Rev A
HYDRAULICS
6
Lift Circuit Hydraulic Schematic
See Figures 6-6 and 6-7.
Figure 6-6
1 Operating pressure oil to Steering Valve 4 Charge pressure oil to front wheel motors 7 Drain oil from right front wheel motor
2 Return oil from lift valve 5 Drain oil from left front wheel motor
3 Charge pressure oil from front wheel motors 6 Charge pressure oil to front wheel motor
brakes
MAR0152
.39 ci .39 ci .39 ci
4060 psi
4060 psi
200 psi
2.14 ci
3000
RPM
A
B
Gear
Pump
0.651 ci
0.651 ci
0.651 ci
Front
Reel
Valve
A
B
P
G
T
SOL3
SOL1
0.651 ci
0.651 ci
Rear
Reel
Valve
A
B
P
G
T
SOL4
SOL2
Right Front
Reel Motor
Left Rear
Reel Motor
Right Rear
Reel Motor
Center
Reel Motor
Left Front
Reel Motor
10
Micron
25 psi
Crack
Bypass
Charge
Filter
Oil
Cooler
100
Mesh
Screen
507 PSI
CHG
DR
PB1
PB2
Brake
Valve
1
4
5 6 7
3
2
