4-44 673831-Rev A
ELECTRICAL
4
Unused Circuits
The harness contains wiring for additional circuits that
are not used on this mower. The associated input and
output circuits are disabled in the MCU. The unused
circuits are:
• Weight Transfer Solenoid (SOL9) - MCU 2-12
• Left Deck Offset Solenoid (SOL 10) - MCU 6-02
• Right Deck Offset Solenoid (SOL11) - MCU 5-05
• Lower Solenoid 2 (SOL13)
• Lift Solenoid 2 (SOL14)
• Weight Transfer Solenoid 2 (SOL15) - MCU 2-12
• Deck Offset Switch (SW9) - MCU 4-11 and 4-12
