ELECTRICAL
673831-Rev A 4-3
4
Specifications
Test and Adjustment Specifications
Specification
Resistance Across Solenoid Coil—Front Mow
Solenoid Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—Rear Mow
Solenoid Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—Front Backlap
Solenoid Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—Rear Backlap
Solenoid Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—Lower Solenoid
Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—Lift Solenoid Coil at
68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—Parking Brake
Solenoid Coil at 68° F
ohms 10.3 ± 10%
Resistance Across Solenoid Coil—4WD Solenoid Coil
at 68° F
ohms 3.4 ± 10%
Resistance Across Fuel Shutoff Pull-In Coil at 68° F
ohms 0.5 ± 10%
Resistance Across Fuel Shutoff Hold-In Coil at 68° F
ohms 15 ± 10%
Mow/Backlap/Lift/Lower Solenoids Nut Torque
lb-ft (N·m) 10 (13.6)
Parking Brake Solenoid Nut Torque
lb-ft (N·m) 2.5 (3.4)
4WD Solenoid Nut Torque
lb-ft (N·m) 3 (4.1)
