Textron Jacobsen SLF530 User Manual

HYDRAULICS
673831-Rev A 6-9
6
Hydraulic Schematic
Continued
Figure 6-3
1 Operating pressure oil from gear pump
section 1
2 Return oil to hydraulic tank
MAR0151
GP TT
450 psi
.026
Lift
Valve
Steering Valve
LT
L
R
P
T
E
RT
2100 psi
One Way
Orifice
One Way
Orifice
One Way
Orifice
One Way
Orifice
Left Front
Cylinder
Center
Cylinder
Right Front
Cylinder
4WD Option
Steering
Cylinder
3WD Option
Steering
Cylinder
.032
.032
.032
3
2
1
4
6
9
10
8
Left Rear
Cylinder
Right Rear
Cylinder
.026 .026
One Way
Orifice
One Way
Orifice
1
2
