7-2 673831-Rev A
STEERING
7
Specifications
Test and Adjustment Specifications
Steering System Leakage Test—Cylinder Leakage pt (L) Zero–Nominal Amount
Rear Axle Alignment Toe-In Measurement
(4WD Option)
in. (mm) 0.0625 (1.6)
Rear Axle Spindle Arm-to-Axle Stop Measurement
(4WD Option)
in. (mm) 0.0625 to 0.125 (1.6 to 3.2)
Repair Specifications
Steering Wheel Nut lb-ft (N·m) 25–30 (34–41)
Steering Column-to-Steering Unit Screw Torque
lb-ft (N·m) 15 (20)
Steering Cylinder to-Steering Arm Torque
(3WD Option)
lb-ft (N·m) 103 (140)
Steering Cylinder Ball Joint-to-Steering Arm Torque
(4WD Option)
lb-ft (N·m) 40-55 (55–75)
Tie Rod Ball Joint-to-Steering Arm Torque
(4WD Option)
lb-ft (N·m) 30–35 (40–47)
