TOHATSU MFS 2 Service Manual

6
6-5
4st 2/2.5/3.5 2007
GREASE
OBMOBM
OBM
GREASE
OBMOBM
OBM
GREASE
OBMOBM
OBM
GREASE
OBMOBM
OBM
OIL
GEARGEAR
GEAR
OIL
GEARGEAR
GEAR
TB
13421342
1342
6 N·m (4 lb·ft) [0.6 kgf·m]
7
6
4
5
Gear Case (Propeller Shaft)
1 Ball Bearing, 6004 1
2 Forward Gear( "A"Gear) 1
3 Shim, 21-28-0.1 AR
Shim, 21-28-0.15 AR
4 Propeller Shaft 1
5 Clutch 1
6 Clutch Spring 1
7 Clutch Push Rod 1
8 Propeller Shaft Housing 1
9 Oil Seal, 12-24-8 1
10 O-Ring, 3.2-47 1
11 Ball Bearing, 6001 1
12 Bolt 2 M6 L=20mm
13 Propeller 7(Plastic), 3 x 7.4 x 7 1 Standard
Propeller 6(Aluminum), 3 x 7.4 x 6
1 Option
Propeller 6(Plastic), 3 x 7.4 x 6 1 Option
Propeller 4.5(Plastic), 3 x 7.4 x 4.5
1 Option
14 Shear Pin, 4-24 1
15 Split Pin, 4-35 1
Ref.
No.
Description Remarks
Q'ty
P/L Fig. 11
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
OIL
GEARGEAR
GEAR
GREASE
OBMOBM
OBM
TB
13421342
1342
MFS2sec06070524.qxd07.5.243:20 PM  ページ5
