TOHATSU MFS 2 Service Manual

5
5-17
4st 2/2.5/3.5 2007
9) Removal of Rocker Arm
1. Remove bolts and then cylinder head cover.
2. Remove lock nut 1, and then pivot 2, rocker arm 3 and
push rod 4.
3. Remove pivot bolt 5, and then push rod plate 6.
2
1
2
6
3
1
5
4
MFS2sec05070524.qxd07.5.243:18 PM  ページ17
