TOHATSU MFS 2 Service Manual

5-14
Power Unit
4st 2/2.5/3.5 2007
5) Inspection of Crank Case Head
1. Check crank case head for crack, damage and corrosion.
Replace if necessary.
6) Assembly of Crank Case Head
1. Attach new oil seal 1 to crank case head by using a
commercially available mandrel. Apply lithium grease to
the lip of oil seal.
LIT
GREASE
LIT
1
7) Installation of Crank Case Head
1. Attach a new O ring.
4st OIL
4st
OIL
2. Install crank case head ass'y to cylinder block ass'y.
Crank Case Head Bolt :
6 N · m (4 lb · ft) [0.6 kgf · m]
1
Do not reuse.
Do not reuse.
MFS2sec05070524.qxd07.5.243:18 PM  ページ14
