TOHATSU MFS 2 Service Manual

Ref.
No.
Part Name Remarks
Q'ty
Ref.
No.
Part Name Remarks
Q'ty
9 Clamp, 6.5-67P 1
10 Bolt 2 M6 L=30mm
11 Breather Chamber Cover 1
12 Breather Chamber Cover Gasket 1
13 Bolt 2 M6 L=16mm
14 Spark Plug M12-P1.25 1 DCPR6E [NGK]
15 Breather Hose 1
16 Clip, ø12 2
17 Slinger 1
18 Throttle Cable Bracket 1
19 Clamp, 6.5-67P 1
20 Bolt 2 M6 L=25mm
1 Cylinder-Crankcase 1 with Nipple
1-1 Dowel Pin, 6-12 3
1-2 Bolt 6 M6 L=35mm
1-3 Bolt 2 M6 L=75mm
1-4 Washer 2
2 Cylinder Head Cover 1
3 Cylinder Head Cover Gasket 1
4 Bolt 4 M6 L=16mm
5 Washer, 6-16-1.5 4
6 Thermostat 1 52˚C Mark 5B or 52B
7 Thermostat Cap 1
8 Thermostat Cap Gasket 1
5-6
Power Unit
4st 2/2.5/3.5 2007
17
6
8
7
9
10
10
1
14
4
4
3
2
20
19
20
18
12
11
13
15
16
16
Fig.3-7
1-1
1-2
1-2
1-2
1-2
1-1
1-1
1-3
1-4
1-4
1-3
1-2
5
5
5
4
6 N·m (4 lb·ft) [0.6 kgf·m]
6 N·m (4 lb·ft) [0.6 kgf·m]
6 N·m (4 lb·ft) [0.6 kgf·m]
18 N·m (13 lb·ft) [1.8 kgf·m]
6 N·m (4 lb·ft) [0.6 kgf·m]
1 6 N·m ( 4 lb·ft) [0.6 kgf·m]
2 8.8 N·m (6.5 lb·ft) [0.9 kgf·m]
4st OIL
4st
OIL
271271
LT
271
271518
LT
518
SOC
OIL-COMP.
GM
SOCSOC
Cylinder
P/L Fig. 1
4st
OIL
4st OIL
271518
LT
518
OIL-COMP.
GM
SOCSOC
SOC
271271
LT
271
Do not reuse.
Do not reuse.
Do not reuse.
MFS2sec05070524.qxd07.5.243:18 PM  ページ6
