TOHATSU MFS 2 Service Manual

mark
9-1
9
8
3
5
6
4
8
7
10
1-1
1
2
11
1 5 N·m (4 lb·ft) [0.5 kgf·m]
2 10 N·m (7 lb·ft) [1.0 kgf·m]
4st OIL
4st
OIL
4st OIL
4st
OIL
4st OIL
4st
OIL
LIT
G
REASE
LIT
4st OIL
4st
OIL
4st OIL
4st
OIL
5-8
Power Unit
4st 2/2.5/3.5 2007
Piston & Crank Shaft
P/L Fig. 2
LIT
GREASE
LIT
4st
OIL
4st OIL
Ref.
No.
Part Name Remarks
Q'ty
Do not reuse.
Do not reuse.
Do not reuse.
1 Crankshaft Ass'y 1 with Gear
1-1 Ball Bearing, 6204 1
2 Thrust Plate, 20.2-32-1 1
3 Piston 1
4 Piston Ring Top 1
5 Piston Ring 2nd 1
6 Piston Ring Oil 1
7 Piton Pin 1
8 Piton Pin Clip 2
9 Connecting Rod Ass'y 1
9-1 Connecting Rod Bolt 2
10 Oil Seal, 20-35-7 1
11 Magneto Key 1
