TOHATSU MFS 2 Service Manual

7-7
4st 2/2.5/3.5 2007
7
Nylon Nut 7 and Bracket Bolt 3 :
7 N · m (5 lb · ft) [0.7 kgf · m]
2. Assembling Procedure
1) Assembly of Clamp Bracket
1. Attach distance piece 2 and bracket bolt 3 to clamp
bracket 1.
2. Assemble swivel bracket 4 and clamp bracket 5, thrust
supporter 6,and tighten nylon nut 7 and nut 8 to specified
torque.
7
4
3
1
5
7
8
0
9
2
TB
13421342
1342
TB
13421342
1342
GREASE
OBMOBM
OBM
GREASE
OBMOBM
OBM
6
G
REASE
OBMOBM
OBM
Distance Piece Nut 8 :
6 N · m (4 lb · ft) [0.6 kgf · m]
3. Install thrust rod 9 and tighten clamp screw 0.
2) Installation of Steering Stopper
1. Align holes a of steering stopper 1 and stopper lever 2,
and press fit pin 3.
2. Put steering stopper ass'y 1 into swivel bracket 4 hole b,
and align it with stopper lever 2 and swivel bracket 4 holes
c, and insert bolt 5.
Hook spring 6 on the part e of stop lever 2,
and insert bolt 5 while pushing the spring
against swivel bracket 4 part d.
c
2
1
5
4
b
TB
13421342
1342
TB
13421342
1342
5
3 Tighten steering stopper bolt 5 to specified torque.
2
4
e
6
a3
1
c5
d
b
GREA
SE
OBMOBM
OBM
Steering Stopper Bolt:
6 N · m (4 lb · ft) [0.6 kgf · m]
TB
13421342
1342
TB
13421342
1342
TB
13421342
1342
MFS2sec07070524.qxd07.5.243:21 PM  ページ7
