TOHATSU MFS 2 Service Manual

1 Drive Shaft Housing "S" 1
1-1 Exhaust Plug 1 PT 1/8
2 Dowel Pin, 6-12 2
3 Bolt 7 M6 L=30mm
4 Drive Shaft Housing Gasket 1
5 Water Plug 1 M8 P1.25
6 Gasket, 8.1-15-1 1
7 Grommet, 29-3 1
8 Extension Housing " L" 1 for "L"
9 Drive Shaft Bushing 1
10 Drive Shaft Bushing Stopper 1
11 Grommet, 13-2 1
12 Bolt 2 M6 L=12mm
13 Stud Bolt, 6-171 1 M6 L=171mm
14 Nut 1 M6
15 Bolt, 6-30 Pre-coated 1 M6 L=30mm
16 Gear Case 1
16-1
Ball Bearing, 6000 1
17 Bolt, 6-30 Pre-coated 2 M6 L=30mm
18 Oil Plug 2 ø6
19 Gasket, 8.1-15-1 2
20 Anode 1
21 Bolt 1 M6 L=16mm
22 Steering Bracket 1
Ref.
No.
Part Name Remarks
Q'ty
23 Bolt 2 M8 L=35mm
24 Rubber Hose 1
25 Dowel Pin, 6-12 2
26 Water Pipe "S" 1 for "S"
Water Pipe "L" 1 for "L"
26-1
Water PipeGrommet (Upper) 1
Ref.
No.
Part Name Remarks
Q'ty
1-1
1
4
6
5
22
23
24
25
25
16
17
20
21
16-1
18
18
17
19
19
12
13
11
10
14
15
9
8
7
3
2
2
4st OIL
4st
OIL
4st OIL
4st
O
IL
TB
13421342
1342
5 N·m (4 lb·ft) [0.5 kgf·m]
6 N·m (4 lb·ft) [0.6 kgf·m]
13 N·m (9 lb·ft) [1.3 kgf·m]
TB
13421342
1342
13 N·m (9 lb·ft) [1.3 kgf·m]
TB
13421342
1342
6 N·m (4 lb·ft) [0.6 kgf·m]
6 N·m (4 lb·ft) [0.6 kgf·m]
TB
13421342
1342
10 N·m (7 lb·ft) [1.0 kgf·m]
7 N·m (5 lb·ft) [0.7 kgf·m]
TB
13421342
1342
10 N·m (7 lb·ft) [1.0 kgf·m]
6 N·m (4 lb·ft) [0.6 kgf·m]
OIL
GEARGEAR
GEAR
GREASE
OBMOBMOBM
OBM
26-1
26
1107
TB
11071107
a
TB
13421342
1342
6 N·m (4 lb·ft) [0.6 kgf·m]
7-3
4st 2/2.5/3.5 2007
7
Drive Shaft Housing &
Gear Case
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
a Note: Marked with "SH2 C3"
P/L Fig. 9
OIL
GEARGEAR
GEAR
GREASE
OBMOBM
OBM
TB
13421342
1342
TB
11071107
1107
MFS2sec07070524.qxd07.5.243:21 PM  ページ3
