TOHATSU MFS 2 Service Manual

8
8-3
4st 2/2.5/3.5 2007
1 Flywheel 1
2 Igniter 1
2-1 Plug Cap (with Resistance) 1
3 Bolt 2 M6 L=20mm
4 Bolt 1 M6 L=12mm
5 Flywheel Cover 1
6 Collar, 6.2-9-35 3
7 Stop Switch 1
7-1 Stop Switch Lanyard 1
8 Magneto Nut (10P-1.25) 1 M10
9 Washer 1
Ref.
No.
Part Name Remarks
Q'ty
5
7
2
4
2-1
7-1
3
6
1
8
9
6 N·m (4 lb·ft) [0.6 kgf·m]
18 N·m (13 lb·ft) [1.8 kgf·m]
43 N·m (31 lb·ft) [4.3 kgf·m]
2.3 N·m (1.7 lb·ft) [0.23 kgf·m]
G17G17
BOND
G17
SOC
OIL-COMP.
GM
SOCSOC
a
bb
a Spark Plug
b Igniter Clearance
0.2 - 0.4mm(0.008 - 0.016in)
2. Parts Layout
Magneto
P/L Fig. 6
OIL-COMP.
GM
SOCSOC
SOC
G17G17
BOND
G17
