TOHATSU MFS 2 Service Manual

6
6-13
4st 2/2.5/3.5 2007
1
3
2
GREASE
OBMOBM
OBM
1
OIL
GEARGEAR
GEAR
15) Assembly of Pump Case (Lower)
1. Apply gear oil to outside of new oil seal 1, and attach it to
pump case (lower) 3 with numbered side down by using a
commercially available mandrel 2.
2. Apply OBM grease to lip of oil seal 1.
16) Removing Clutch Cam and Cam Rod
1. Pull cam rod ass'y 1 upward to remove.
1
18) Inspection of Clutch Cam and Cam
Rod
1. Check cam rod 1 and clutch cam 3 for cracks and wear.
Replace if necessary.
19) Assembly of Clutch Cam and Cam
Rod
1. Install clutch cam 3 and spring pin 2 to cam rod 1.
17) Disassembly of Clutch Cam and
Cam Rod
1. Remove spring pin 2 and clutch cam 3 from cam rod 1.
Use spring pin tool A to remove spring pin.
Do not reuse removed spring pin.
OIL
GEARGEAR
GEAR
1
3
2
2
Spring Pin Tool A :
P/N. 345-72227-0
2
Do not reuse.
2
Do not reuse.
Spring Pin Tool B :
P/N. 345-72228-0
MFS2sec06070524.qxd07.5.243:20 PM  ページ13
