TOHATSU MFS 2 Service Manual

Bracket
7-8
4st 2/2.5/3.5 2007
3) Installation of Drive Shaft Housing
1. Install drive shaft housing 1 to swivel bracket 2 and tighten
bolts 3 to specified torque.
3
3
TB
13421342
1342
TB
13421342
1342
1
2
Swivel Bracket Bolts 3 :
10 N · m (7 lb · ft) [1.0 kgf · m]
Bring projection steering bushing to dent of
swivel bracket when installing the part.
2
1
4st OIL
4st
OIL
4) Installation of Water Pipe
1. Install water pipe 1 into drive shaft housing 2.
TB
13421342
1342
MFS2sec07070524.qxd07.5.243:21 PM  ページ8
