TOHATSU MFS 2 Service Manual

6
6-11
4st 2/2.5/3.5 2007
9) Assembly of Propeller Shaft Ass'y
1. Put clutch spring 1 and attach clutch 3 to propeller shaft 2.
1
3
2
4
When installing clutch 3, push down clutch
spring 1 by using a bladed screw driver 4.
10) Disassembly of Propeller Shaft
Housing
1. Remove bearing 1 by using commercially available bearing
puller.
1
1
CAUTION
· Do not reuse removed bearing.
· When reusing bearing without removing it,
check it for play or deflection. Replace if
necessary.
2. Remove oil seal 2.
2
11) Inspection of Propeller Shaft
Housing
1. Use cleaning oil and cleaning brush to clean propeller shaft
housing, and check it for cracks or damage. Replace if
necessary.
2. When reusing bearing without removing it, check it for play
or deflection. Replace if necessary.
Do not reuse.
2
Do not reuse.
MFS2sec06070524.qxd07.5.243:20 PM  ページ11
