TOHATSU MFS 2 Service Manual

6-22
Lower Unit
4st 2/2.5/3.5 2007
å L-Transom Model
2
2
3
TB
13421342
1342
TB
13421342
1342
1342
1342
A
2. Attach lower unit ass'y to drive shaft housing, and tighten
lower unit installation bolts 2 (nut 3 ) to specified torque.
Lower Unit Installation Bolts 2 :
10 N · m (7 lb · ft) [1.0 kgf · m]
Lower Unit Installation Nut 3 :
6 N · m (4 lb · ft) [0.6 kgf · m]
3. Install cam rod 1 to joint 4 and tighten bolt 3 to specified
torque.
Joint Bolt 3 :
6 N · m (4 lb · ft) [0.6 kgf · m]
6
3
4
3
1
4st OIL
4st
OIL
4. Attach grommet 6 to drive shaft housing.
5. Attach shear pin and propeller, insert split pin, and bend the
tip.
WARNING
Before removing or installing propeller, be
sure to disconnect spark plug cap and
remove stop switch lock plate.
GREASE
OBMOBM
OBM
· Connect water pipe securely.
· Move flywheel a little to align the drive shaft
spline to crank shaft spline.
TB
13421342
1342
MFS2sec06070524.qxd07.5.243:20 PM  ページ22
