TOHATSU MFS 2 Service Manual

2-7
2
4st 2/2.5/3.5 2007
F2A F2.5A F3.5A
Unit
Outboard Model
Item
L (US gal.)
Type
API
SAE
NMMA
Quantity
㎤ (fl.oz)
Type
*1 API
*1 SAE
Quantity
㎤ (fl.oz)
[Marking]
in(mm)
Steps
*2 Degrees
*3 Degrees
*4 Degrees
mm(in)
Fuel&Oil
Type of Fuel
Unleaded Gasoline (Research Octan Number 90
or over, Pump posted Octane Number 87 or over)
Fuel Tank Capacity
1.0 (0.26) [Integral Fuel Tank]
Starting Fuel Enrichment System
Choke Valve System
Fuel Pumping (Feed) System
None (Gravitational System)
4-Stroke Engine (Motor) Oil
Grade
SF, SG, SH
10W-30, 10W-40
FC-W Certified 10W-30
300 (10)
Hypoid Gear Oil
Grade
GL-5
#90
180 (6)
LowerUnit
Gear Shift Positions
Forward(F) - Neutral(N)
Gear Ratio
2.15(13 : 28)
Type of Gears
Spiral Bevel Gear
Clutch
Dog Clutch
Propeller Shaft Driving
Shear Pin
Propeller Rotation Direction
Clockwise at forward (F) shift as viewed from rear
Propeller (Standard)
[I7] 3 x 7 x 7
(3 x 188 x 178) Plastic
Bracket
No. of Trim Steps
4
Trim Angle (Transom 12°)
-7ﾟ- +8ﾟ
Max. Tilt Angle
65°
*1 Requirements of both API and SAE shall be met.
*2 Angle of propeller shaft relative to horizon when transom angle is 12 degrees.
*3 Range of tilt angle
*4 Starboard-port full steering range
Steering Angle
360°
Max. Allowable Transom Thickness
30 - 58 (1.18 - 2.28)
WarningSystem
Over-revolution Protection
Controls engine speed to 6,300 r/ min or lower
(High Speed ESG)
OptionalParts
Propeller
(No. of Blades x Diameter x Pitch)
[Marking]
in(mm)
[F6] 3 x 7 x 6
(3 x 188 x 145)
[B6] 3 x 7 x 6
(3 x 188 x 145)
[ ] 3 x 7 x 4.5
(3 x 188 x 110)
3
8
3
8
3
8
3
8
･ Plastic
･ Aluminum
･ Plastic
Engine Oil Gear Oil
MFS2sec02070524.qxd07.5.243:12 PM  ページ7
