Shift Lever Body
●
Betweenthe body and O-Ring
O-Rings (2 pcs.)
●
Whole area of the part
Spring
●
Whole area of the part
Ceramic Ball
●
Whole area of the part
Exhaust Plug
●
Outer circumference of insertion area
Threaded areaof Lever bolt and shift rod
Inner area of shift lever shaft insertion hole
Grommet
●
Drive shaft housing contact area
Bolt,Stud Bolt (Drive Shaft Housing Joint)
●
Threaded area
Nut (Drive Shaft Housing Joint)
●
Threaded area
Drive Shaft
●
Crankshaft side spline
Ball Bearings (2 pcs.)
●
At press fit
Bolts (Lower Unit)
●
Threaded area
Bolts (Pump Case)
●
Threaded area
●
Lip area
●
Outer circumference, at press fit
Grommet
●
Insertion area outer circumference, at
press fit
O-Rings 2 pcs.
(Cam Rod Bushing)
●
Whole area of the part
Bolts
(Propeller Shaft Housing)
●
Threaded area
O-Ring
●
Whole area of the part
●
Lip area
●
Outer circumference, at press fit
Propeller Shaft
●
Propeller contact area
Clamp Screw
●
Threaded area
Tilt Stopper
●
Entire circumference of shaft area
Thrust Supporter
●
Sliding area
Steering Bushing
●
Sliding area
Thrust Bushing
●
Sliding area
Steering Stopper
●
Inner area of split pin insertion hole
Bolt (Steering Stopper)
●
Threaded area
Stopper Spring
●
Coil area, both ends
Stopper Lever
●
Inner area of split pin insertion hole
Friction Adjust Screw
●
Threaded area
Clamp Bracket
●
Inside of sliding area
Swivel Bracket
●
Threaded area
Bolts (Bracket)
Nylon Nuts
●
Threaded area
Bolts (Distance Piece) Nuts
●
Threaded area
Oil Seal
(Pump Case Lower)
2-15
2
4st 2/2.5/3.5 2007
Gear Oil
4-stroke Engine Oil
Silicon Grease
Teflon Grease
Waterproof Grease
Low Temperature
Resistant
Lithium Grease
Adheasive
Gasket Seal Agent
Screw Lock Agent
LIT
OBM
TEF
SOC
Lower Unit
