7-31
4st 25/30 2022
7
5) Disassembly of Drive Shaft Housing
1. Remove the upper rubber mount installation bolts 1 and
remove the rubber mounts 2 and the dampers 3 from
the drive shaft housing.
2. Check the rubber mounts 2 and dampers 3 for
abnormalities such as cracks and fissures. Replace if any
abnormality is found.
3. Remove the idle exhaust port cover bolt, then remove the
idle exhaust port cover 4, gasket 5, and plate 6.
Loosen the idle exhaust port cover bolts in the
order shown in the diagram.
4. Check the idle exhaust port cover and interior for sludge,
cracks, fissures, or other abnormalities.
To Next Page
