Bevel Gear B Nut Wrench
P/N. 346-72231-0
Bevel Gear B Nut Socket
P/N. 346-72232-0
Shimming Gauge
P/N. 346-72250-0
Thickness Gauge
P/N. 353-72251-1
Removal/installation of pinion nut (B gear nut)
Bevel gear B
height adjustment
Measurement of gaps
Piston Slider
P/N. 3AC-72871-0
Spring Pin Tool A
P/N. 345-72227-0
Spring Pin Tool B
P/N. 345-72228-0
Torque Wrench
P/N. 3AC-99070-0
Installation of piston
Removal of spring pin
(ø3.0)
Installation of spring pin
(ø3.0)
Adjustment of
valve clearance
Oil Filter Wrench
P/N. 3AC-99090-0
Piston Ring Tool
P/N. 353-72249-0
Spark Tester
P/N. 3F3-72540-0
Clamp Pliers
P/N. 3T5-72864-0
Removal/installation of
oil filter
Removal/installation of
piston rings
Spark inspection OETIKER clamp crimper
Valve Clearance Driver
P/N. 3AC-99071-0
Tachometer
P/N. 3AC-99010-0
Compression Gauge
P/N. 3AC-99030-0
Vacuum/Pressure Gauge
P/N. 3AC-99020-1
Adjustment of
valve clearance
Measurement of
engine revolution speed
Measurement of
compression pressure
Inspection of pressure
1-6
Service Information
4st 25/30 2022
17
3) Special Tools
