TOHATSU MFS 25d Service Manual

2-9
2
4st 25/30 2022
Electric
Control
Unit
(ECU)
Fuel
Control
Idle
AirControl
Ignition
Timing
Control
Display
Control
Fuel
Air
③FuelFilter②FuelConnector
⑤VaporSeparator
⑨FuelInjector
IntakeManifold
FuelCooler
⑪Venthosenipple
OpentoAir
⑧FuelRail
①FuelTank
④FuelPump
Alternator
(ExciterCoil)
PulserCoil
(CrankPositionSensor)
EngineTemperatureSensor
ThrottlePositionSensor
(TPS)
StopSwitch
OilPressureSwitch
FuelFeedPump
(FFP)
FuelInjector
ISC
(IdleSpeedControlValve)
IgnitionCoil
WarningBuzzer
WarningLamp
(LED)
Tachometer
⑦FuelRegulator
⑥FuelFeedPump(FFP)
⑩VaporCatchTank
MAP(Intakepressure)
Sensor
MAT(Intakeair
temperature)Sensor
T-MapSensor
1
2
2
6
7
8
9
0
q
3
4
5
MF,EFmodel
Exceptfor
MF,EFmodel
2. Fuel Injection System
1) ECU Fuel Feed System
The ECU uses various sensors to precisely control the injected fuel amount (time) and ignition timing.
